Stainless Steel Bollard Malaysia
Product Overview
The BBIM B01-00108-BBIM stainless steel bollard is a heavy-duty access control solution engineered for Malaysian commercial, industrial and institutional environments. Manufactured from SS201 stainless steel with a BA (Bright Annealed) mirror finish, this stainless steel bollard stands 750mm tall with a 4-inch (100mm) outer diameter — a profile that delivers maximum visibility to approaching drivers while remaining accessible to pedestrians and wheelchair users.
Available exclusively through safety-bbasb.com — Malaysia’s specialist in road and pedestrian safety products — this bollard is built for longevity with a 1.2mm-wall SS201 tube, a 3mm stainless steel base plate, and a stainless steel half ball cap that seals the hollow post against water and debris ingress.
According to the World Health Organization, road traffic injuries remain a leading cause of death globally, underlining the critical importance of well-designed physical barriers in high-pedestrian zones. The BBIM SS201 bollard directly addresses this need by creating a clear, immovable separation between vehicle and foot-traffic areas at your property.
This bollard integrates seamlessly with products from our broader Safety Cones & Bollards category, and can be combined with traffic barriers, road studs and reflectors, and flexible bollards and road barriers for a comprehensive site-safety solution. For enhanced nighttime awareness, supplement with our convex mirrors range.
Malaysian workplaces and public areas fall under the oversight of DOSH Malaysia (Department of Occupational Safety and Health), which mandates that employers provide a safe working environment under the Occupational Safety and Health Act 1994. Installing stainless steel bollards at vehicular entry points is a recognised engineering hazard control measure that helps meet these obligations.
Product Specifications
| PRODUCT SPECIFICATIONS | |
| Brand | BBIM |
| Model Number | B01-00108-BBIM |
| Material | SS201 Stainless Steel |
| Finish | BA (Bright Annealed / Mirror Polished) |
| Bollard Diameter | 4 inch / 100mm |
| Wall Thickness | 1.2mm |
| Height | 750mm |
| Cover Diameter | 180mm |
| Base Plate Thickness | 3mm Stainless Steel |
| Cap Type | 4-inch (100mm Dia) Stainless Steel Half Ball |
| Approximate Weight | 2.6 kg / Unit |
| Colour / Appearance | BA (Bright Annealed) Polished Silver |
| Mounting | Surface mount via base plate (bolts not included) |
| Application | Car parks, driveways, pedestrian zones, commercial premises |
| Corrosion Resistance | Good (SS201); suitable for covered/semi-outdoor use in Malaysia |
| Standards Compliance | Suitable for DOSH & local traffic safety guidelines (Malaysia) |
PRO Tips — Installation & Maintenance
|
PRO INSTALLATION & MAINTENANCE TIPS 1. Always confirm the concrete slab or paving depth before installation — a minimum 150mm-thick concrete base is recommended for secure anchor bolting of the base plate. 2. Use stainless steel hex bolts (M10, M12 or M16) matching the SS201 grade to prevent bimetallic corrosion between the base plate and the fasteners. 3. Apply a thin bead of silicone sealant beneath the base plate perimeter after anchoring to prevent water pooling and surface staining at the bolt penetrations. 4. For high-vehicle-impact zones such as loading bays, consider supplementing with flexible bollards from the safety-bbasb.com range as outer perimeter pre-warning protection. 5. BA (Bright Annealed) finish should be cleaned regularly with a pH-neutral stainless steel cleaner — avoid chlorine-based agents that can pit SS201 over time. 6. Plan bollard spacing at 1,200mm to 1,500mm centre-to-centre to effectively prevent car access while remaining compliant with pedestrian and wheelchair passage requirements. 7. Pair stainless steel bollards with reflective road studs or convex mirrors from safety-bbasb.com for enhanced nighttime visibility and safer pedestrian zones. |
Applications
Category 1 — Commercial & Retail Properties
- Shopping mall entrances and car park access lanes
- Retail storefront pedestrian protection from vehicles
- Bank, hotel and office tower driveways
- Restaurant al fresco dining perimeter protection
Category 2 — Industrial & Institutional Sites
- Warehouse loading bay pedestrian segregation
- Factory and manufacturing plant entry control
- Hospital and healthcare facility patient drop-off zones
- Government building and infrastructure protection
Category 3 — Public Spaces & Infrastructure
- Pedestrian walkways and footpath delineation
- School and university bus drop-off zones
- Public park entrances and cycling path separation
- Stadium and event venue crowd management zones
Features & Benefits-
Stainless Steel Bollard Malaysia
| FEATURE | BENEFIT |
| SS201 Stainless Steel Construction | Excellent corrosion and oxidation resistance for long-term outdoor durability in Malaysia’s tropical climate |
| BA (Bright Annealed) Mirror Finish | Premium aesthetic appearance suited for high-end commercial, retail and hospitality environments |
| 3mm Heavy-Duty Base Plate | Provides stable, secure floor anchoring to withstand accidental vehicle impact loads |
| 4-Inch Half Ball Stainless Steel Cap | Protects hollow tube from water, dirt and debris ingress, significantly extending service life |
| 1.2mm Wall Tube Thickness | Balances structural rigidity with manageable weight (~2.6 kg) for easy installation by two workers |
| 180mm Cover Diameter Shroud | Conceals the base plate for a clean, professional look at entrances and access points |
| 750mm Working Height | Optimal height to stop vehicles while maintaining full driver visibility and pedestrian accessibility |
| Versatile Surface-Mount Design | Compatible with both new-pour concrete and existing paved surfaces for flexible deployment |
Frequently Asked Questions (FAQ)-
Stainless Steel Bollard Malaysia
| Q1: What is the diameter of the BBIM B01-00108-BBIM stainless steel bollard? |
| A: The BBIM B01-00108-BBIM stainless steel bollard has a 4-inch (100mm) outer diameter tube with a 1.2mm wall thickness. The cover shroud extends to 180mm diameter over the base plate. |
| Q2: What grade of stainless steel is used in this bollard? |
| A: This bollard is manufactured from SS201 stainless steel — an austenitic, low-nickel grade offering good corrosion resistance and widely used in Malaysian commercial and light industrial applications. |
| Q3: What does BA finish mean on a stainless steel bollard? |
| A: BA stands for Bright Annealed — a controlled-atmosphere heat treatment producing a highly reflective, mirror-like surface without mechanical polishing. It combines aesthetic appeal with a protective oxide layer. |
| Q4: How is the BBIM stainless steel bollard installed? |
| A: The bollard uses a 3mm stainless steel surface-mount base plate anchored to the ground using expansion or chemical anchors. It does not require core drilling, making installation straightforward. |
| Q5: How much does each bollard unit weigh? |
| A: Each bollard unit weighs approximately 2.6 kg, making it manageable for placement and a two-person anchor installation without heavy equipment. |
| Q6: Is this stainless steel bollard suitable for outdoor use in Malaysia? |
| A: Yes. SS201 stainless steel performs well in covered outdoor, semi-outdoor and indoor environments typical of Malaysian commercial properties. For full seacoast or highly corrosive environments, SS304 grade may be more appropriate. |
| Q7: Can the bollard be removed after installation? |
| A: The B01-00108-BBIM is a fixed surface-mount bollard. For removable options, please contact the BBIM team at safety-bbasb.com to enquire about available removable bollard variants. |
| Q8: What is the recommended spacing between stainless steel bollards? |
| A: For standard vehicle access control, 1,200mm to 1,500mm centre-to-centre spacing is recommended. This prevents car access while allowing pedestrians and wheelchair users to pass freely between the bollards. |
Customer Pain Points & BBIM Solutions
| CUSTOMER PAIN POINT | BBIM SOLUTION |
| Vehicles parking in restricted zones | The 750mm-high, 100mm-diameter bollard creates a clear, immovable physical barrier that prevents unauthorized vehicle entry without requiring staff supervision. |
| Corrosion from humidity and tropical rain | SS201 stainless steel with BA finish provides excellent resistance to oxidation and humidity, making it a long-lasting solution for Malaysia’s tropical climate. |
| Ugly barriers ruining property aesthetics | The mirror-like BA polished finish and streamlined half ball cap complement modern architectural finishes in commercial lobbies, malls and office parks. |
| Bollards that are difficult to install | The surface-mount base plate design enables quick installation — no specialist contractor needed, reducing project downtime and installation costs significantly. |
| Maintenance-heavy safety infrastructure | Stainless steel requires only periodic cleaning with a neutral cleaner — no painting, no rust-treatment, and no recoating cycles over the product lifetime. |
Technical Documentation & Order CTA
Included Components
- 1x SS201 stainless steel tube — 100mm OD, 1.2mm wall, 750mm height
- 1x SS201 stainless steel half ball cap — 4 inch (100mm dia)
- 1x SS201 stainless steel base plate — 3mm thick
- 1x Bollard cover shroud — 180mm diameter
Not Included
- Anchor bolts / expansion anchors (M10, M12 or M16 stainless recommended)
- Concrete adhesive or chemical anchors for soft-ground fixing
Packaging & Logistics
- Individually wrapped in protective foam sleeve
- Standard pallet quantity: 20 units per pallet
- CBM: approximately 0.08 m3/unit
- Lead time: 7-14 working days (standard order); 21-30 days (OEM/custom run)
|
READY TO ORDER? – Stainless Steel Bollard MalaysiaContact our team for bulk pricing, OEM orders, and custom specifications. Visit: https://www.safety-bbasb.com Email: bybigplus@blue-box.asia | WhatsApp or Call for fastest response |
Why Choose BBIM?
BBIM (Brand: BBIM / BB) is Malaysia’s trusted supplier of industrial and road safety equipment, distributed through safety-bbasb.com. Our products are sourced from ISO-certified manufacturers and undergo rigorous quality control inspection before dispatch. We offer:
- OEM / private label manufacturing for custom bollard requirements
- Competitive ex-stock and bulk-order pricing across Malaysia
- Technical support and installation guidance from our team
- Nationwide delivery across Peninsular Malaysia and East Malaysia
- Full product range: bollards, cones, barriers, road studs, convex mirrors, fencing
Disclaimer-Stainless Steel Bollard Malaysia
Product specifications, dimensions, weights and availability are subject to change without notice. All images are for illustration purposes only. Actual product may differ slightly from images shown. BBIM / BB Safety Products makes no warranty, express or implied, regarding suitability for any specific application. Buyers are advised to verify compliance with local authority requirements including DOSH Malaysia (dosh.gov.my) prior to procurement. Pricing is subject to confirmation at point of order.
